$44.99
Product Features:
- Smart all-in-one telemetry
- Fast, powerful 32-bit ARM M4 processor
- Multiple options for easy programming:
- Smart ESC Programming Box
- SmartLink USB Updating and Programmer application
- Throttle stick programming
- Multi-point protection:
- Over-current protection
- Automatic LiPo low-voltage cutoff
- Thermal protection
- Failsafe protection
Developed and designed by Spektrum engineers, in partnership with the industry's leading ESC manufacturer
Specifications:
- Adjustable Timing: No
- Amperage: 15A
- Application: Air
- Auto Cutoff: Yes
- BEC: Yes
- BEC Continous Current: 3A
- BEC Maximum Burst Current: 12A
- BEC Type: Linear
- BEC Voltage: 5.2V
- Brakes: Yes
- Connector Type: IC2
- ESC Type: Brushless
- Forward: Yes
- Input Voltage: 2S - 4S LiPo
- Low-Voltage Cutoff Programmable: Yes
- Max Input Voltage: 14.8V
- Maximum Burst Current: 25A
- Maximum Continuous Current: 15A
- Motor Output Lead: 2mm
- Part Type: Electronics
- Product Application: Air
- Product Height: 0.4" (10 mm)
- Product Length: 1.4" (36 mm)
- Product Weight: 0.6oz (16g)
- Product Width: 0.6" (15 mm)
- Programmable: Yes
- Programming Options: Transmitter Stick Input, Programming Box, On Screen Text Gen, Smartlink App
- Reverse: Yes
- Technology : Smart
- Compact for easy installation in most applications
- Ready to install — no soldering required
- Heat dissipating design
- Dual BEC power connectors
- Firmware updatable through the Smart ESC Programming Box and SmartLink PC application
- High heat-resistant IC™ connectors, backwards compatible with EC™ connectors
- Limited 1-year warranty
